Introducing the all-new Abound SR—the enhanced cargo ebike built to carry anything and tackle every challenge. Whether you're cruising through the streets or bike pooling with a friend, the Abound SR is always ready for any action. Its compact frame keeps you agile, while advanced security† and GPS† features give you total peace of mind.

Outfitted with an adjustable quill stem, suspension seatpost, and cutting-edge theft deterrent features†, every ride is smooth, secure, and stress-free. Whether it’s a quick trip or a big haul, the Abound SR is your go-to for dominating the road.

It’s SRsly fun.

General Info

ModelAbound SR EbikeWeight80 lbsTotal Weight Limit440 lbsRider Height4'11" - 6'3"Ebike ClassClass 2 EbikeIdeal UseCargo & UtilityPedal Assist3 Levels (with Ride Tune Customization)Safety CertificationsUL and TUV Safety Certified
UL 2849RangeUp to 60 milesFoldingNoBattery Safety CertificationsCertified to UL 2271Carry CapacityCarry A Single PassengerWater ResistanceBike - IPX5 // Components - IPX6

Frameset

ForkThreaded Steerer Tube for Quill Stem 15x110 spacing, 50mm travel, adjustable lockout, black stanchionsFrame StyleStep-ThroughFrame6061 Aluminum Alloy with Internal Battery. One piece - Diecast aluminum front triangle

Wheelset

Tires20 x 3.0 urban tire with reflective sidewallsWheels20-inch, 12-gauge, 36-hole, double-wall aluminum, black

Ebike System

Motor Torque80NmECUAventon ECU Module featuring wired CAN communication, GPS positioning support, wireless Bluetooth connectivity, and cellular communication capabilitiesThrottleAventon LH Handlebar MountedSensorsDouble Sided Bottom Bracket Torque SensorChargerAventon 4A 42VDisplayAventon BC147SpeedClass 2BatteryAventon 36V, 20Ah, 733Wh, LG 21700 cellsMotorShengyi 36V 750w Hub Drive with 6 speed sensors (1188W peak)

Brakes

Rear Brake RotorTektro 203mm 6 boltFront BrakeTektro HD-E3520 hydraulic disc brakesRear BrakeTektro HD-E3520 hydraulic disc brakesFront Brake RotorTektro 180mm 6 bolt

Drivetrain

Chain122 Link, 8 SpeedChainring52 toothCrankset3pc, 165mm crank armRear DerailleurShimano Altus RD-M310 8 SpeedShift LeverShimano SL-M315-8R 8 SpeedCassetteShimano CS-HG200-8 8 speed Cassette, 12-32TPedals9/16" Composite PlatformChainring BCD130

Cockpit

SaddleAventon by SelleRoyalSeatpost30.9mm Aventon Suspension Seatpost with 50mm travelHandlebarsBMX Style, 31.8mm bar clamp, 680mm widthStemQuill Stem with 31.8mm bar clamp diameter, 40mm length, and 140mm of vertical adjustmentSeat Clamp34.9mm Quick ReleaseGripsLock-on ergonomic

Included Accessories

Rear RackIncludedKickstandIncluded: E-lockRear Wheel Mesh GuardsIncludedRear Rack Weight Limit143 lbs
